Product Summary

The ATmega88V-10MU is a low-power CMOS 8-bit microcontroller based on the AVR enhanced RISC architecture. By executing powerful instructions in a single clock cycle, the ATmega88V-10MU achieves throughputs approaching 1 MIPS per MHz allowing the system designer to optimize power consumption versus processing speed.

Parametrics

ATmega88V-10MU absolute maximum ratings: (1)Operating temperature: -55℃ to +125℃; (2)Storage temperature: -65℃ to +150℃; (3)Voltage on any pin except RESET with respect to ground: -0.5V to VCC+0.5V; (4)Voltage on RESET with respect to ground: -0.5V to +13.0V; (5)Maximum operating voltage: 6.0V; (6)DC current per I/O pin: 40.0mA; (7)DC current VCC and GND pins: 200.0mA.

Features

ATMEGA88V-10MU features: (1)Capacitive touch buttons, sliders and wheels; (2)QTouch and QMatrix acquisition; (3)Up to 64 sense channels; (4)DebugWIRE on-chip debug system; (5)Power-on reset and programmable brown-out detection; (6)Internal calibrated oscillator; (7)External and internal interrupt sources; (8)Five sleep modes: Idle, ADC noise reduction, power-save, power-down, and standby; (9)23 programmable I/O lines; (10)28-pin PDIP, 32-lead TQFP, 28-pad QFN/MLF and 32-pad QFN/MLF

Diagrams

ATMEGA88V-10MU block diagram

Image Part No Mfg Description Data Sheet Download Pricing
(USD)		 Quantity
ATmega88V-10MU
ATmega88V-10MU
Atmel
8-bit Microcontrollers (MCU) 8kB Flash 0.5kB EEPROM 23 I/O Pins
Data Sheet
0-1: $1.65
1-10: $1.60
10-25: $1.45
25-100: $1.33
ATMEGA88V-10MUR
ATMEGA88V-10MUR
Atmel
8-bit Microcontrollers (MCU) AVR 8K FLSH 1K SRAM 512B EE-10MHz
Data Sheet
0-5000: $1.33
5000-6000: $1.33
