AT24C512B-PU25

AT24C512B-PU25, DIP, Two-wire Serial EEPROM, 5.0 mA, 1.0V to +7.0V

Rated 5 Rating 5 | reviews | Write a review

Price:: US $1.57~2.50 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $1.57~2.50

PartNumber:: AT24C512B-PU25

Brand:: ATMEL Corporation - ATMEL | Pack: DIP | D/C: 10+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Ms. Katherina's store

(China (Mainland))

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2012-08-09

From Other Seller

Part Number:AT24C512B-PU25
US $1.57 - 2.50
ECA1HHG4R7

US $10.00 - 10.00 / Piece
(0) Remove
HEF4093BT

US $0.15 - 1.20 / Piece
(0) Remove
Quantity:

piece

Product Summary

The AT24C512B-PU25 is a two-wire Serial EEPROM with three device address inputs. It provides 524,288 bits of serial electrically erasable and programmable read only memory (EEPROM) organized as 65,536 words of 8 bits each. The AT24C512B-PU25 is cascadable feature allows up to eight devices to share a common two-wire bus. The device is optimized for use in many industrial and commercial applications where low-power and low-voltage operation are essential. The AT24C512B-PU25 is available in space-saving 8-pin PDIP, 8-lead JEDEC SOIC, 8-lead EIAJ SOIC, 8-lead TSSOP, 8-ball dBGA2 and 8-lead Ultra Thin SAP packages. In addition, the entire family is available in 1.8V (1.8V to 3.6V) and 2.5V (2.5V to 5.5V) versions.

Parametrics

AT24C512B-PU25 absolute maximum ratings: (1)Operating Temperature: 55℃ to +125℃; (2)Storage Temperature: 65℃ to +150℃; (3)Voltage on Any Pin with Respect to Ground: 1.0V to +7.0V; (4)Maximum Operating Voltage: 6.25V; (5)DC Output Current: 5.0 mA.

Features

AT24C512B-PU25 features: (1)Low-voltage and Standard-voltage Operation; (2)1.8v (VCC = 1.8V to 3.6V); (3)2.5v (VCC = 2.5V to 5.5V); (4)Internally Organized 65,536 x 8; (5)Two-wire Serial Interface; (6)Schmitt Triggers, Filtered Inputs for Noise Suppression; (7)Bidirectional Data Transfer Protocol; (8)1 MHz (2.5V, 5.5V), 400 kHz (1.8V) Compatibility; (9)Write Protect Pin for Hardware and Software Data Protection; (10)128-byte Page Write Mode (Partial Page Writes Allowed); (11)Self-timed Write Cycle (5 ms Max); (12)High Reliability; (13)Endurance: 1,000,000 Write Cycles; (14)Data Retention: 40 Years; (15)Lead-free/Halogen-free Devices; (16)8-lead PDIP, 8-lead JEDEC SOIC, 8-lead EIAJ SOIC, 8-lead TSSOP, 8-ball dBGA2, and 8-lead Ultra Thin Small Array (SAP) Packages; (17)Die Sales: Wafer Form, Waffle Pack and Bumped Die.
